For outstanding performance in light-weight applications the 906F sets the standard for stability, power, fuel consumption and operational efficiency.

FEATURES
  • Fully pressurized and sealed cab with excellent all-around visibility.
  • Environmentally efficient powertrain maximizes torque output and achieves higher breakout force at lower engine speeds.
  • Load sensing hydraulics and auto idle technology
  • World-class components with proven quality and availability.
SPECIFICATIONS
Base
Operating Weight 5,600 kg
Rated Power 35.9 kW (48 hp/49 ps) @ 2000 rpm
Bucket Capacity 0.21 m³
Performance
Arm Digging Force 31 kN
Bucket Digging Force 41 kN
Transport Dimension
Shipping Length 5,900 mm
Shipping Width 1,960 mm
Shipping Height 2,630 mm
Track Shoe Width (STD) 400 mm
Engine
Model Yanmar 4TNV94L-ZCWCLY
Emission EU Stage IIIA
Hydraulic System
System Maximum Flow 136 L/min
System Pressure 25 MPa
