LiuGong Excavators,Unmatched performance driven by the Cummins Engine enhances torque output with more power and breakout force at lower engine speeds.Options for auxiliary hydraulic piping include bidirectional variable high flow line, an additional line for rotating attachments and also a single acting line. The quick coupler further ensures you get the most out of your machine by easily switching between a wide range of attachments to suit any application.

FEATURES
  • Three new power modes of 922F - Power, Standard and Eco. Using Cummins VGT technology engine, delivers 5% more torque. 6 electronic fans, reduce power consumption by 60%
  • Extra tough chassis - reduces stress by 10%;  extra strong boom & arm - reduces stress by 30%.
  • Electro-hydraulic control technology, boom float technology and attachment flow and pressure control, all these make the operation more convenient.
  • Equipped with 360 degree camera and around level daily inspection.
  • The NVH design reduces wind resistance and noise. Compared with traditional direct-drive fans our new electronic fans are quieter by 9%. The external radiated noise of the machine is best in class at 68dB.
SPECIFICATIONS
Base
Operating Weight 22,800 kg
Rated Power 116 kW @ 2200 rpm
Bucket Capacity 1.1 m³
Performance
Arm Digging Force 105 kN
Bucket Digging Force 152.5 kN
Transport Dimension
Shipping Length 9,620 mm
Shipping Width 2,990 mm
Shipping Height 3,000 mm
Track Shoe Width (STD) 600 mm
Engine
Model Cummins B6.7
Emission Stage V / Tier 4F
Hydraulic System
System Maximum Flow 2×214.5 L/min
System Pressure 37.3 MPa
