FEATURES
  • Fully electronically controlled hydraulic system with pure electric drive, easy to control, more energy-saving and environmentally friendly. Fewer maintenance items, lower maintenance costs, energy costs compared with diesel excavators to save more than 60%.
  • Large-capacity lithium iron phosphate battery, longer cycle life, better safety performance. Cobalt-free, more environmentally friendly.
  • One-key switching of operation mode, delayed extinguishing of LED lights, and more expansion contents such as voice control and 5G remote driving are also included.
  • Newly upgraded cab, green sunscreen glass, high-definition touch instrumentation with multi-function navigation keys, more ergonomic, more comfortable to drive, ride and operate.
  • Multi-module electronic fan, according to the temperature of the intelligent variable speed, can be reversed to clean, intelligent and casual, save time and worry.
SPECIFICATIONS
Base
Operating Weight 24,100 kg
Rated Power 165 kW
Bucket Capacity 1.0 m³
Performance
Arm Digging Force 105 kN
Bucket Digging Force 152.5 kN
Drawbar Pull 200 kN
Transport Dimension
Shipping Length 9,910 mm
Shipping Width 3,090 mm
Shipping Height 2,985 mm
