When you want high engine power and maximum thrust, Furthermore, it offers superior operational comfort and convenient maintenance procedures..

FEATURES
SUPERIOR ENGINE PERFORMANCE
  • The LD20D engine boasts a rated power of 154 kW, exceeding the industry standard by 10%, ensuring robust power output and optimal operational efficiency.
THE POWER’S IN YOUR HANDS
  • It is equipped with the luxurious cabin, integrating a high-capacity air conditioning system for enhanced comfort and featuring noise levels that are notably lower than industry averages.
BUILT TO LAST LONGER
  • Adopting a pivot-type chassis, the vehicle employs modularized powertrain components designed for prolonged service life and ease of maintenance, effortlessly tackling harsh working conditions.
SPECIFICATIONS
Base
Operating Weight 17,500 kg
Engine Power 154 kW
Attachments
Blade Capacity 4.5 m³
Blade Lift Height 1,100 mm
Blade Cutting Depth 510 mm
Ground Pressure 55.8 kPa
Engine Displacement 8.9 L
Track Shoe Width 510 mm
Number of Rollers (Per Side) 6
Number of Idlers (Per Side) 2
Number of Track Shoes (Per Side) 39
1st Gear Speed (Forward) 3.6 km/h
2nd Gear Speed (Forward) 6.6 km/h
3rd Gear Speed (Forward) 10.6 km/h
1st Gear Speed (Reverse) 4.3 km/h
2nd Gear Speed (Reverse) 7.8 km/h
3rd Gear Speed (Reverse) 12.6km/h
