Fast and efficient the 936E delivers class leading cycle times, consistently loading more material for less.
When you want the fastest, most efficient loading performance the 936E delivers. Thanks to a perfect combination of the super-efficient Cummins engine, LiuGong’s advanced hydraulics, a perfectly matched arm and bucket and faster swing speeds, the 936E consistently moves more – for less.
Tough, repetitive tasks like breaking and loading can lead to operator fatigue and reduced productivity. We give operators total control keeping them fresh and alert with a light, responsive hydraulic control joystick. This smart technology gives effortless control of the hydraulics ensuring that the operator moves the maximum amount of material with the minimum of effort.
Our spacious, fully pressurized ROPS cab provides a clean, quiet, and safe environment and fully meets stringent ISO standards, but we go further. Our fast acting, powerful air conditioning provides the perfect temperature for the operator no matter how hot the climate.
| Operating Weight | 35,000 kg |
| Rated Power | 214 kW (287 hp / 291 ps) @ 2,100 rpm |
| Bucket Capacity | 1.6-2.3 m³ |
| Arm Digging Force | 185 kN |
| Bucket Digging Force | 252 kN |
| Shipping Length | 11,167 mm |
| Shipping Width | 3,190 mm |
| Shipping Height | 3,530 mm |
| Track Shoe Width (STD) | 600 mm |
| Model | Cummins QSL9 |
| Emission | EU Stage IIIA |
| System Maximum Flow | 2×300 L/min |
| System Pressure | 37.3 MPa |
